Meet Core AI

Highlight

Apple introduced Core AI, an end-to-end AI framework covering model conversion, optimization, compilation, and on-device inference. It lets developers deploy models locally on Apple Silicon through a familiar PyTorch workflow, with no server dependency and zero per-token cost.

Core Ideas

The pain of on-device AI

Running an AI model inside an app used to require a long path. First you trained the model in Python, then found a tool to convert it into a format the device could run, perhaps passing through an intermediate layer such as ONNX. After conversion, you still had to worry about numerical correctness, performance, and whether the first load would freeze the user. Every step introduced friction.

Apple hit the same problems while running Apple Intelligence. Core ML worked, but it was not ideal for modern workloads such as Transformers. Rather than patching around it, Apple wrote a new framework from the ground up and is now opening it to all developers.

What Core AI is

Core AI is not just an inference framework. It covers the full model deployment lifecycle (00:59):

• Use coreai-torch on the Python side for model conversion and optimization
• Use the CoreAI framework on the Swift side for inference
• Use Xcode for AOT compilation, dedicated Instruments, and a visual Debugger

The toolchain has a clear goal: let developers keep the familiar PyTorch workflow while benefiting from full-stack Apple Silicon acceleration across CPU, GPU, and Neural Engine.

A concrete example: AI plays Snake

The speaker demonstrates Core AI with a two-player Snake game where one snake is driven by an AI model (03:51). The example is small, but it uses the same tools and APIs as a 70B-parameter large model.

The model is a simple Transformer. Its input is a feature representation of the game board state, and its output is action logits for the four directions. Training data comes from naive simulation: run a few games and record states and actions.

Model conversion: from PyTorch to .aimodel

The conversion flow is straightforward (05:08):

import torch
import coreai_torch

pt_model = SnakeTransformer().load_checkpoint("snake.pt")
example = torch.randn(1, 5, 16)

seq_len = torch.export.Dim("seq_len", min=1, max=256)
exported = torch.export.export(
    pt_model, args=(example,),
    dynamic_shapes={"features": {1: seq_len}},
)
exported = exported.run_decompositions(coreai_torch.get_decomp_table())

ai_program = coreai_torch.TorchConverter().add_exported_program(
    exported, input_names=["features"], output_names=["logits"],
).to_coreai()

ai_program.save_asset("SnakeTransformer.aimodel")

Key points:

• torch.export exports a PyTorch model as a static computation graph
• dynamic_shapes declares that sequence length is dynamic, with a range from 1 to 256
• coreai_torch.get_decomp_table() provides the operator decomposition rules Core AI needs
• The final output is an .aimodel file, which Xcode can open directly to inspect structure

After conversion, you should perform numerical validation (05:44):

import torch
import numpy as np
from coreai.runtime import AIModel, NDArray

pt_model = SnakeTransformer().load_checkpoint("snake.pt")
ai_model = await AIModel.load("SnakeTransformer.aimodel")
function = ai_model.load_function("main")

features = np.array([extract_features(game) for _ in range(10)],
                    dtype=np.float32)[np.newaxis]

with torch.no_grad():
    pytorch_logits = pt_model(torch.from_numpy(features)).numpy()[0, -1]

result = await function({"features": NDArray(data=features)})
coreai_logits = result["logits"].numpy()[0, -1]

max_diff = np.max(np.abs(pytorch_logits - coreai_logits))
assert max_diff < 0.01

Key points:

• Run PyTorch and Core AI with the same inputs
• Compare the maximum difference between output logits
• Set the threshold according to business needs; this example uses 0.01

Swift-side inference: basic usage

Core AI’s Swift API uses progressive disclosure (07:41). The simplest usage requires only three types:

import CoreAI

let model = try await AIModel(contentsOf: modelURL)
let mainFunction: InferenceFunction = try model.loadFunction(named: "main")!
let inputNDArray: NDArray = nextInput()
var outputs = try await mainFunction.run(inputs: ["input": inputNDArray])

guard let outputNDArray = outputs.remove("output")?.ndArray else {
    // Handle unexpected missing output
}

Key points:

• AIModel loads the .aimodel file and parses the model structure
• InferenceFunction is the runnable computation graph, usually named “main”
• NDArray carries multidimensional input and output data
• run is asynchronous and does not block the main thread

Wrap it in a game player type (08:33):

struct ModelPlayer {
    let nextActionFunction: InferenceFunction

    init(modelURL: URL) async throws {
        let model = try await AIModel(contentsOf: modelURL)
        self.nextActionFunction = try model.loadFunction(named: "main")!
    }
}

The actual decision logic (08:49):

extension ModelPlayer: SnakePlayer {
    mutating func chooseAction(game: SnakeGame) async throws -> Direction {
        var inputFeatures = NDArray(
            shape: [game.stepCount, hiddenDim],
            scalarType: .float32
        )
        writeFeatures(of: game, into: inputFeatures.mutableView())

        var outputs = try await nextActionFunction.run(
            inputs: ["features": inputFeatures]
        )
        guard let logits = outputs.remove("logits")?.ndArray else {
            throw ModelError.missingOutput
        }

        return predictedDirection(from: logits.view())
    }
}

Key points:

• NDArray.MutableView is a non-escapable type that provides safe and efficient access to underlying storage
• mutableView() gets a writable view, while view() gets a read-only view
• The input feature shape is [stepCount, hiddenDim], and the first dimension grows dynamically

Input features include distance to each wall, relative position of the nearest food, one-hot encoding of the current direction, and the opponent snake’s distance and direction (10:10).

Performance problem: Transformer’s quadratic complexity

After the game starts running, it becomes slower over time (10:42). Instruments shows that the interval between inferences grows noticeably. The cause is that Transformer complexity is O(n^2) with respect to sequence length, and every Snake step increases the history length.

The solution is a KV Cache (11:20). On every inference, a Transformer recomputes the key and value embeddings for the whole sequence. If previously computed key/value values are stored, the next inference only needs to compute the new token, reducing complexity from O(n^2) to O(n).

Implementing KV Cache with State

Core AI’s State mechanism makes this simple. State is an input that is both read and updated in place during inference (11:48).

First, add cache buffers to the PyTorch model (12:18):

class SnakeTransformerStateful(nn.Module):
    def __init__(self, ...):
        super().__init__()
        self.register_buffer(
            "k_cache", torch.zeros(N_LAYERS, 1, MAX_SEQ_LEN, D_MODEL))
        self.register_buffer(
            "v_cache", torch.zeros(N_LAYERS, 1, MAX_SEQ_LEN, D_MODEL))

Read and write the cache in forward (12:50):

def forward(self, features, position_ids):
    new_k, new_v = [], []
    for i, block in enumerate(self.blocks):
        k_prev = self.k_cache[i]
        v_prev = self.v_cache[i]
        # ... compute q/k/v for the new token ...
        new_k.append(k_updated)
        new_v.append(v_updated)

    self.k_cache.copy_(torch.stack(new_k))
    self.v_cache.copy_(torch.stack(new_v))
    return self.action_head(self.ln_final(x))

Declare state_names when converting the model again (12:59):

ai_program = coreai_torch.TorchConverter().add_exported_program(
    exported,
    input_names=["features", "position_ids"],
    state_names=["keyCache", "valueCache"],
    output_names=["logits"],
).to_coreai()

Store and pass the cache on the Swift side (13:17):

struct ModelPlayer {
    let nextActionFunction: InferenceFunction
    var keyCache: NDArray
    var valueCache: NDArray

    init(modelURL: URL) async throws {
        let model = try await AIModel(contentsOf: modelURL)
        self.nextActionFunction = try model.loadFunction(named: "main")!
        self.keyCache = NDArray(
            shape: [layers, maxContext, hiddenDim],
            scalarType: .float32
        )
        self.valueCache = NDArray(
            shape: [layers, maxContext, hiddenDim],
            scalarType: .float32
        )
    }
}

Pass state views during inference (13:45):

mutating func chooseAction(game: SnakeGame, snakeID: Int) async throws -> Direction {
    // ... prepare inputFeatures ...

    var stateViews = InferenceFunction.MutableViews()
    stateViews.insert(&keyCache, for: "keyCache")
    stateViews.insert(&valueCache, for: "valueCache")

    var outputs = try await nextActionFunction.run(
        inputs: ["features": inputFeatures],
        states: stateViews
    )
    // ...
}

Key points:

• register_buffer lets PyTorch export the cache as mutable buffers
• state_names tells the converter which buffers should become Core AI state
• The Swift side wraps multiple state values in a MutableViews collection and updates them in place during inference
• After adding KV Cache, game speed stays stable and no longer slows down over time

Model specialization and caching

An .aimodel file is a source format that can run on any Apple device. Before it actually loads, it must go through specialization, which generates optimized executable code for the specific device’s CPU, GPU, and ANE (15:41).

Specialization can be slow for large models. Core AI provides a caching mechanism (16:22):

let cache = AIModelCache.default

guard let model = try cache.model(for: modelURL, options: .default) else {
    Task { @MainActor in
        informUser("Preparing AI features. This may take a while...")
    }
}

You can also proactively trigger specialization (16:42):

try await AIModel.specialize(contentsOf: modelURL)

Apple recommends calling this immediately after the user enables a feature or after the model resource finishes downloading, rather than triggering it in the middle of an interaction flow.

Specialization has two steps (17:31): compilation, including graph partitioning, planning, and optimization, and generation of device-specific executable artifacts. Compilation takes most of the time. Xcode supports AOT (Ahead-of-Time) compilation, which precompiles models on the development machine and reduces specialization time on user devices (17:57).

Advanced optimization APIs

For tight loops that need maximum performance, Core AI also provides lower-level APIs (18:39):

• Query the optimal memory layout for NDArray and preallocate memory to avoid layout conversion during inference
• Preallocate output values to avoid dynamic memory allocation during inference
• Use async values to pipeline execution across multiple inference functions

Most scenarios only need the high-level APIs. These lower-level APIs are available when optimizing critical paths.

Details

Full PyTorch model conversion flow

From a trained PyTorch model to an .aimodel file, the core steps are exporting a static computation graph, applying Core AI operator decompositions, then converting and saving. Here is a complete conversion example:

import torch
import coreai_torch

# 1. Load the PyTorch model and prepare an example input
pt_model = SnakeTransformer().load_checkpoint("snake.pt")
example = torch.randn(1, 5, 16)

# 2. Define a dynamic dimension, where sequence length can vary
seq_len = torch.export.Dim("seq_len", min=1, max=256)

# 3. Export as a static computation graph
exported = torch.export.export(
    pt_model, args=(example,),
    dynamic_shapes={"features": {1: seq_len}},
)

# 4. Apply the operator decompositions Core AI requires
exported = exported.run_decompositions(coreai_torch.get_decomp_table())

# 5. Convert to a Core AI program and save it
ai_program = coreai_torch.TorchConverter().add_exported_program(
    exported, input_names=["features"], output_names=["logits"],
).to_coreai()

ai_program.save_asset("SnakeTransformer.aimodel")

Key points:

• torch.export.export() captures a PyTorch dynamic graph as a static computation graph, which is the prerequisite for conversion
• dynamic_shapes declares which dimensions are dynamic, avoiding separate conversions for every sequence length
• coreai_torch.get_decomp_table() provides operator decomposition rules supported by Core AI, splitting complex PyTorch operators into primitive operations Core AI can recognize
• .aimodel is a cross-device source format that Xcode can open directly to inspect model structure and tensor shapes

Always perform numerical validation after conversion to ensure accuracy loss is acceptable:

import torch
import numpy as np
from coreai.runtime import AIModel, NDArray

pt_model = SnakeTransformer().load_checkpoint("snake.pt")
ai_model = await AIModel.load("SnakeTransformer.aimodel")
function = ai_model.load_function("main")

features = np.array([extract_features(game) for _ in range(10)],
                    dtype=np.float32)[np.newaxis]

with torch.no_grad():
    pytorch_logits = pt_model(torch.from_numpy(features)).numpy()[0, -1]

result = await function({"features": NDArray(data=features)})
coreai_logits = result["logits"].numpy()[0, -1]

max_diff = np.max(np.abs(pytorch_logits - coreai_logits))
assert max_diff < 0.01

Key points:

• Run PyTorch and Core AI with the same inputs and compare the final logits
• Set the threshold according to business needs; classification tasks are often fine within 0.01
• If the difference is too large, check whether the dynamic_shapes range covers the test input and whether any operator decomposition is missing

Swift-side inference and model wrapping

Core AI’s Swift API follows the principle of progressive disclosure. The most basic usage requires only three types:

import CoreAI

// 1. Load the model from an .aimodel file
let model = try await AIModel(contentsOf: modelURL)

// 2. Get the main inference function, usually named "main"
let mainFunction: InferenceFunction = try model.loadFunction(named: "main")!

// 3. Prepare input and run inference
let inputNDArray: NDArray = nextInput()
var outputs = try await mainFunction.run(inputs: ["input": inputNDArray])

guard let outputNDArray = outputs.remove("output")?.ndArray else {
    // Handle unexpected missing output
}

Key points:

• AIModel parses the .aimodel file structure and does not execute computation itself
• InferenceFunction is the compiled runnable computation graph, and a model can contain multiple functions
• NDArray is Swift’s representation of a multidimensional array, supporting scalar types such as float32 and int64
• run is an async method that does not block the main thread, making it suitable for UI interactions

In real projects, inference logic is usually wrapped in a business type. Here is a complete game AI player implementation with model loading, feature writing, and action selection:

struct ModelPlayer {
    let nextActionFunction: InferenceFunction

    init(modelURL: URL) async throws {
        let model = try await AIModel(contentsOf: modelURL)
        self.nextActionFunction = try model.loadFunction(named: "main")!
    }
}

extension ModelPlayer: SnakePlayer {
    mutating func chooseAction(game: SnakeGame) async throws -> Direction {
        // 1. Create an input NDArray with shape [current step count, feature dimension]
        var inputFeatures = NDArray(
            shape: [game.stepCount, hiddenDim],
            scalarType: .float32
        )

        // 2. Safely write feature data through MutableView
        writeFeatures(of: game, into: inputFeatures.mutableView())

        // 3. Run inference
        var outputs = try await nextActionFunction.run(
            inputs: ["features": inputFeatures]
        )

        // 4. Extract output logits and decode them into an action direction
        guard let logits = outputs.remove("logits")?.ndArray else {
            throw ModelError.missingOutput
        }

        return predictedDirection(from: logits.view())
    }
}

Key points:

• NDArray.MutableView is Swift’s non-escapable type, providing memory safety with zero overhead
• mutableView() returns a writable view for input preparation, while view() returns a read-only view for output reading
• The first dimension of the input feature shape grows dynamically with the game step count, which is exactly why KV Cache optimization is needed
• Features include distance to each wall, nearest-food relative position, current-direction one-hot value, and the opponent snake’s distance and direction

Model specialization and caching mechanism

.aimodel is a cross-device source format. Before running, it needs specialization: generating optimized executable code for the specific device’s CPU, GPU, and ANE. Specialization can be slow for large models, so Core AI provides caching and pre-triggering:

// Check whether a specialized model already exists in the cache
let cache = AIModelCache.default

guard let model = try cache.model(for: modelURL, options: .default) else {
    // Cache miss: tell the user to wait
    Task { @MainActor in
        informUser("Preparing AI features. This may take a while...")
    }
}

// Proactively trigger specialization, recommended immediately after the user enables a feature or a model download completes
try await AIModel.specialize(contentsOf: modelURL)

Key points:

• AIModelCache.default caches specialization results by device model, so the same device can hit the cache on the next load
• On cache miss, provide clear feedback to avoid unexplained stalls during an interaction flow
• specialize() is asynchronous and should run on a non-critical path, such as after settings are changed or a download completes
• Specialization has two steps: compilation, including graph partitioning, planning, and optimization, and generation of device-specific executable artifacts. Compilation takes most of the time
• Xcode supports AOT (Ahead-of-Time) compilation, which can precompile the model on the development machine and reduce waiting on user devices

Core AI toolchain overview

The Core AI stack can be split into three layers:

Python layer: The coreai-torch package supports conversion from PyTorch, direct authoring, Apple Silicon optimization, and custom kernels written with Metal 4. Advanced use cases mentioned in the talk are covered in session 325, Dive into Core AI model authoring and optimization.

Swift layer: The CoreAI framework provides type-safe APIs and uses Swift’s non-escapable types to guarantee memory safety without sacrificing performance.

Tooling layer: Xcode integration includes AOT compilation, Core AI-specific Instruments, a visual Debugger that can trace tensor values back to Python source lines, and the Xcode Debug Gauge for showing Core AI activity in real time.

Core AI Models repository

Apple maintains an official model repository (19:26) containing:

• One-command conversion recipes for popular models
• AI skills specialized in Core AI conversion and optimization
• A Swift package with high-level APIs for specific model families and built-in low-level optimizations
• APIs for creating a Core AI Language Model that can connect to the Foundation Models framework

Key Takeaways

1. Run local image classification inside an app

What to build: Convert a trained ResNet or ViT into .aimodel with coreai-torch, then load and run inference from Swift in a few lines.

Why it is worth doing: No network requests, private data stays on device, and there is no API call cost. For high-frequency features such as photo classification or object recognition, on-device inference has clear latency and cost advantages.

How to start: Convert the model with coreai-torch, load it on the Swift side with AIModel(contentsOf:), get the inference function with loadFunction(named: "main"), and pass an NDArray to run it. Entry APIs: AIModel(contentsOf:) + InferenceFunction.run

2. Add an AI opponent to a game

What to build: Like the Snake example in the talk, train a Transformer to learn a game strategy and run real-time inference on device with Core AI.

Why it is worth doing: On-device inference removes network latency, so the AI opponent can respond to game state in real time. KV Cache solves the performance decline caused by growing Transformer sequence length, so long matches do not get slower over time.

How to start: Define k/v cache with register_buffer in the PyTorch model, declare it with state_names during conversion, then pass and update the cache from Swift with InferenceFunction.MutableViews. Entry APIs: state_names + InferenceFunction.MutableViews

3. On-device text generation

What to build: Get a preconverted LLM from the Core AI Models repository and connect it through the Foundation Models framework.

Why it is worth doing: User input is processed locally, with zero token cost and no privacy-sensitive upload. For chat assistants and text summarization, on-device execution removes network and server dependencies.

How to start: Download a preconverted model from the Core AI Models repository, load it with CoreAILanguageModel, and create a LanguageModelSession for generation. Entry APIs: CoreAILanguageModel(resourcesAt:) + FoundationModels framework

4. Real-time audio processing

What to build: Use a small model for voice activity detection or speaker separation, with Core AI scheduling CPU, GPU, and ANE together for low latency.

Why it is worth doing: Audio processing is extremely latency-sensitive, and on-device inference avoids network round trips. For small models like these, the ANE is far more energy efficient than CPU or GPU and can run continuously in the background without significant battery drain.

How to start: Call AIModel.specialize(contentsOf:) when the user first enables the feature, compiling the model ahead of time to avoid stutters during interaction. Tune with Core AI-specific Instruments. Entry APIs: AIModel.specialize + Core AI Instruments

5. Custom vision models

What to build: Author a Core AI computation graph directly on the Python side, write Metal 4 kernels for custom operators, then integrate the model into the app.

Why it is worth doing: Standard operator libraries do not cover every emerging research model architecture. Custom kernels let you deploy new operators from papers directly to Apple Silicon while benefiting from GPU and ANE hardware acceleration.

How to start: Build the computation graph with the coreai-torch authoring API, implement the custom operator with a hand-written Metal Shading Language kernel, and register it during conversion with register_custom_kernels. Entry APIs: coreai-torch authoring API + Metal 4 custom kernels

Related Sessions

• Dive into Core AI model authoring and optimization - A deep dive into model authoring, optimization, and custom kernels with the Core AI Python package
• Integrate Core AI into your app - Best practices for integrating Core AI into apps
• Explore MLX Swift - Apple’s Swift bindings for the MLX framework, a complementary local AI option alongside Core AI
• Bring your model to Apple silicon - The lower-level mechanics of Metal tensor operations and model deployment
• Foundation Models on device - The Foundation Models framework for on-device large language models
