SwiftData: Dive into inheritance and schema migration

SwiftData: Dive into inheritance and schema migration

App ServicesSwift
Watch original video

Highlight

Starting with iOS 26, SwiftData supports inheritance between @Model classes. Combined with a lightweight migration stage, you can move an existing schema to V4 with subclasses without disruption.

Core content

The SampleTrips example app evolved from iOS 17 all the way to iOS 26. The first model had only one Trip class. Every kind of trip — family, business, wellness — went into the same table. The problems showed up over time. A business trip needs a perdiem field. A personal trip needs a Reason enum (family/reunion/wellness). Adding both to Trip bloats the base class, and most fields make no sense for the other kind. Splitting into flat tables (PersonalTrip, BusinessTrip standing alone) loses the unified base-class view of “list all my trips.”

iOS 26 adds class inheritance to SwiftData: @Model classes can inherit from each other. Trip is the base class with shared fields. PersonalTrip and BusinessTrip are subclasses, each with their own properties. When @Query uses the base type, the result includes every subclass instance (deep search). The is keyword inside a predicate filters down to one subclass (shallow search). Rishi Verma also walks through the full migration chain from V1 to V4: V1→V2 custom dedup, V2→V3 unique/index, V3→V4 lightweight migration that wires the subclasses straight in.

Detailed content

How to write a subclass. Subclasses must be marked @available(iOS 26, *), otherwise the code will not compile on older versions.

@Model
class Trip {
  var name: String
  var destination: String
  var startDate: Date
  var endDate: Date

  var bucketList: [BucketListItem] = [BucketListItem]()
  var livingAccommodation: LivingAccommodation?
}

@available(iOS 26, *)
@Model
class BusinessTrip: Trip {
  var perdiem: Double = 0.0
}

@available(iOS 26, *)
@Model
class PersonalTrip: Trip {
  enum Reason: String, CaseIterable, Codable {
    case family
    case reunion
    case wellness
  }
  var reason: Reason
}

Key points (03:28):

  • BusinessTrip: Trip inherits every property of the base class. No need to redeclare them.
  • New properties on a subclass must have a default value (perdiem = 0.0), otherwise old data has nothing to fill in during migration.
  • Reason must conform to Codable for SwiftData to persist it.

Register the subclasses. List them in the modelContainer when registering the schema:

.modelContainer(for: [Trip.self, BusinessTrip.self, PersonalTrip.self])

Key point (04:03): if you only register the base class, fetches for subclasses return nothing.

Use is for shallow search. When a segmented control filters by type, the predicate uses $0 is PersonalTrip:

let classPredicate: Predicate<Trip>? = {
  switch segment.wrappedValue {
  case .personal:
    return #Predicate { $0 is PersonalTrip }
  case .business:
    return #Predicate { $0 is BusinessTrip }
  default:
    return nil
  }
}()
_trips = Query(filter: classPredicate, sort: \.startDate, order: .forward)

Key points (07:06):

  • Predicate<Trip> takes the base class as its type parameter, so the same @Query can fetch every Trip and also filter by type at runtime.
  • The default branch returns nil, dropping the type filter — the same as a deep search.

The full migration plan chain. Connect V1 through V4 with SchemaMigrationPlan:

enum SampleTripsMigrationPlan: SchemaMigrationPlan {
  static var schemas: [any VersionedSchema.Type] {
    var currentSchemas: [any VersionedSchema.Type] =
      [SampleTripsSchemaV1.self, SampleTripsSchemaV2.self, SampleTripsSchemaV3.self]
    if #available(iOS 26, *) {
      currentSchemas.append(SampleTripsSchemaV4.self)
    }
    return currentSchemas
  }

  static var stages: [MigrationStage] {
    var currentStages = [migrateV1toV2, migrateV2toV3]
    if #available(iOS 26, *) {
      currentStages.append(migrateV3toV4)
    }
    return currentStages
  }
}

Key points (10:24):

  • The schemas array lists every schema version in release order. SwiftData uses it to find which version the user is on.
  • stages is a chain of migration steps: V1→V2 and V2→V3 each dedup, V3→V4 is lightweight.
  • #available wraps V4 so an older OS running the older app never touches the unsupported subclass types.

A lightweight stage takes one line. Adding a subclass is a schema-compatible change, so no willMigrate is needed:

@available(iOS 26, *)
static let migrateV3toV4 = MigrationStage.lightweight(
  fromVersion: SampleTripsSchemaV3.self,
  toVersion: SampleTripsSchemaV4.self
)

Key point (10:03): a lightweight migration only declares the source and target versions. The storage engine updates the schema and keeps every existing record.

Three tricks to speed up fetch. Custom migration stages and widgets can tune the same FetchDescriptor:

var fetchDesc = FetchDescriptor<SampleTripsSchemaV1.Trip>()
fetchDesc.propertiesToFetch = [\.name]
fetchDesc.relationshipKeyPathsForPrefetching = [\.livingAccommodation]

Key points (13:11):

  • propertiesToFetch loads only the columns you actually use. When migration dedup needs only name, IO drops sharply.
  • relationshipKeyPathsForPrefetching pulls relationships in one shot, dodging later N+1 queries.
  • Pair it with fetchLimit = 1 (13:28) so the widget grabs only the latest trip.

Efficient History token fetch. Cross-process changes ride on SwiftData History. The new sortBy and fetchLimit mean finding the latest token no longer scans the full table:

var historyDesc = HistoryDescriptor<DefaultHistoryTransaction>()
historyDesc.sortBy = [.init(\.transactionIdentifier, order: .reverse)]
historyDesc.fetchLimit = 1

let transactions = try context.fetchHistory(historyDesc)
if let transaction = transactions.last {
  historyToken = transaction.token
}

Key point (16:24): sorting by transactionIdentifier descending with limit 1 is the same as ORDER BY ... DESC LIMIT 1 in SQL. You get the latest token in O(log n) and skip rescanning the whole history at every launch.

Takeaways

  • What to do: spot a group of “is-a” models in an existing SwiftData app and introduce subclasses.

    • Why it pays off: when business fields keep piling up, subclasses express domain meaning better than optional fields, and you stop scattering if let perdiem checks everywhere.
    • How to start: list every optional field in your current models that only matters for some instances. Cluster them by use case. Each cluster is a subclass candidate.

  • What to do: use “deep search vs shallow search” as the test for inheritance.

    • Why it pays off: it stops you from wiring inheritance everywhere and tanking query performance. If you only query by base class, demote the subclass to a property. If you only query by subclass, flatten the model.
    • How to start: scan every @Query and FetchDescriptor in your code. Count base-class queries against subclass queries. Only consider inheritance if both counts are non-zero.

  • What to do: build a complete SchemaMigrationPlan covering every version from V1 to today.

    • Why it pays off: users do not upgrade in order. They might jump from a two-year-old version straight to the latest. A missing stage means lost data or a crash.
    • How to start: tag each release with a Schema.Version in VersionedSchema, and chain the matching MigrationStage into the plan’s stages array.

  • What to do: use propertiesToFetch + fetchLimit in read-only, low-memory contexts like widgets and share extensions.

    • Why it pays off: a widget has only tens of MB of memory budget. Loading every Trip can OOM outright. Pulling only the needed columns and the most recent record is enough to render the card.
    • How to start: review every FetchDescriptor. If the UI shows only a few fields, write them into propertiesToFetch. If you only show a count or the latest entry, add fetchLimit.
