Demystify SwiftUI performance

Demystify SwiftUI performance

SwiftUIPerformance
Watch original video

Highlight

SwiftUI in iOS 17 and macOS Sonoma allows developers to useSelf._printChanges()To locate redundant refreshes, use@ObservableReduce the scope of dependencies and use a stable ForEach content structure to avoid full reconstruction, thereby systematically improving the interface response speed.

Core Content

Too many dependencies lead to unnecessary refreshes

You must have encountered this situation when writing SwiftUI: an irrelevant property is modified, and the entire view tree is recalculated. For example, on a page that displays dog details, you only want to update the dog’s name, but the picture is also refreshed.

（03:59）

SwiftUI uses a dependency graph to determine which views need to be updated. Each view’s body is calculated based on its input values ​​and dynamic properties. whenDogWhen the structure changes, all subviews that depend on it will be recalculated. The problem is, some subviews don’t actually need to knowDogall information.

（04:05）

Apple’s solution is to narrow the scope of dependencies. Instead of putting the wholeDogobject passed toScalableDogImage, it is better to pass only what it needsImage. In this way, when other attributes of the dog change, the picture view will not receive any update notification.

（08:48）

Synchronous blocking makes the interface stuck

Another common scenario is doing time-consuming operations during view initialization. For example, if you are@StateObjectinit()Initiate a network request inside, this request will block the main thread, causing the interface to freeze.

（12:22）

The correct approach is to move time-consuming operations to asynchronous tasks and use.taskModifiers are executed when the view appears. This way the body can be returned immediately and the interface remains responsive.

（12:23）

Identity Trap of List and Table

In order to support advanced functions such as selection, sliding operations, and reordering, List and Table need to determine the identity of each row when they are created. This means that the contents of the ForEach must produce a fixed number of views.

（15:12）

If you use a conditional view in ForEach orAnyView, SwiftUI cannot know in advance how many views each row corresponds to, and can only create all views. There is no problem when the amount of data is small, but there will be obvious lags when the amount of data is large.

（16:08）

Moving the filtering logic to the model layer and letting ForEach only be responsible for display can greatly improve the loading and scrolling performance of large lists.

（17:35）

Detailed Content

use_printChanges()Locate redundant dependencies

SwiftUI provides a debugging toolSelf._printChanges(), you can print out the reason that triggered the view update.

struct ScalableDogImage: View {
    @State private var scaleToFill = false
    var dog: Dog

    var body: some View {
        let _ = Self._printChanges()
        dog.image
            .resizable()
            .aspectRatio(
                contentMode: scaleToFill ? .fill : .fit)
            .frame(maxHeight: scaleToFill ? 500 : nil)
            .padding(.vertical, 16)
            .onTapGesture {
                withAnimation { scaleToFill.toggle() }
            }
    }
}

（04:02）

Key points:

  • let _ = Self._printChanges()Place it at the beginning of body and the reason will be printed on the console every time the view is updated.
  • print@SelfIndicates that the value of the view itself has changed (i.e. the incomingdogchanged)
  • print@scaleToFillexpress@StateProperties have changed
  • This method is prefixed with an underscore and is for debugging only. Do not submit it to the App Store.

When you see the picture view becausedog.nameWhen refreshed due to changes, you know that the dependency scope is too large. BundledogChange todog.imageAfterwards, changing the name will not trigger the image refresh.

（08:46）

struct DogView: View {
    @Environment(\.isPlayTime) private var isPlayTime
    var dog: Dog

    var body: some View {
        DogHeader(name: dog.name, breed: dog.breed)
        ScalableDogImage(dog.image)
        DogDetailView(dog)
        LetsPlayButton()
            .disabled(dog.isTired)
    }
}

Key points:

  • ScalableDogImageNow only receiveImage, no longer relies on the entireDog
  • DogHeaderstand alone and only receivenameandbreed- The dependencies of each subview are clearly visible at the call site

Change synchronous blocking to asynchronous loading

// Problematic code: fetch data synchronously in init
struct DogRootView: View {
    @State private var model = FetchModel()

    var body: some View {
        DogList(model.dogs)
    }
}

@Observable class FetchModel {
    var dogs: [Dog]

    init() {
        fetchDogs() // Synchronous blocking
    }

    func fetchDogs() {
        // Takes a long time
    }
}

（12:22）

// After the fix: fetch asynchronously
struct DogRootView: View {
    @State private var model = FetchModel()

    var body: some View {
        DogList(model.dogs)
            .task { await model.fetchDogs() }
    }
}

@Observable class FetchModel {
    var dogs: [Dog]

    init() {}

    func fetchDogs() async {
        // Takes a long time
    }
}

（12:23）

Key points:

  • .taskThe modifier starts an asynchronous task when the view appears, and the view creation itself does not block -fetchDogs()marked asasync, can be used internallyawaitMake network requests -@ObservableAutomatically track attribute reads, onlydogsView updates are triggered when changes occur

Avoid variable number of views in List

// Problem: conditional views force List to create all views to determine identity
List {
    ForEach(dogs) { dog in
        if dog.likesTennisBalls {
            DogCell(dog)
        }
    }
}

（16:08）

// Fix: move filtering logic to the model layer
List {
    ForEach(tennisBallDogs) { dog in
        DogCell(dog)
    }
}

（17:35）

Key points:

  • List needs to know the identity of all rows in advance
  • If the content of the ForEach contains conditional branches, SwiftUI must create all possible views of each element to determine the number of rows
  • Put filtering at the model layer. The data received by ForEach is already filtered, and only one view is generated for each row.
  • For grouped lists, nested ForEach is recommended, and SwiftUI will handle this structure specially
// Sectioned List is a valid use of nested ForEach
struct DogsByToy: View {
    var model: DogModel

    var body: some View {
        List {
            ForEach(model.dogToys) { toy in
                Section(toy.name) {
                    ForEach(model.dogs(toy: toy)) { dog in
                        DogCell(dog)
                    }
                }
            }
        }
    }
}

（18:25）

Simplified initialization of Table

iOS 17 and macOS Sonoma introduce a simplified Table initialization method:

// iOS 16 approach
struct DogTable: View {
    var dogs: [Dog]

    var body: some View {
        Table(of: Dog.self) {
            // Columns
        } rows: {
            ForEach(dogs) { dog in
                TableRow(dog)
            }
        }
    }
}

（19:21）

// New iOS 17 approach, automatically creates TableRow
struct DogTable: View {
    var dogs: [Dog]

    var body: some View {
        Table(of: Dog.self) {
            // Columns
        } rows: {
            ForEach(dogs)
        }
    }
}

（19:22）

Key points:

  • New initialization method automatically created for each data elementTableRow- This ensures that there is only one view per row and identity calculation is more efficient
  • This API is backward compatible to the system version first supported by Table
  • Note the semantic change: ifTableRowDifferent data are used (such asdog.bestFriend), in iOS 17 identity will be based ondograther thandog.bestFriend

Core Takeaways

1. Add to complex lists_printChanges()diagnosis

If your list scrolls stuck or the interface flickers when data is updated, addlet _ = Self._printChanges(), observe the console output after running. If you find that modifying a property triggers the update of a large number of unrelated views, reduce the dependencies to the minimum scope one by one. The entrance is LLDBexpression Self._printChanges()Or add it temporarily in the code.

2. Use@Observablereplace@ObservedObject + @Published

Use it directly in new projects@Observable class ModelDefine the data model, no longer needed in the view@ObservedObjector@StateObject. SwiftUI automatically tracks which properties are actually read and only updates views that actually depend on those properties. The entrance isimport Observation, and then putObservableObjectChange to@Observable。

3. Review the ForEach content in all List/Tables

Check your List and Table to make sure the closure of ForEach does not containifcondition,AnyViewor nested mutable structures. If there is conditional filtering, move it to the ViewModel. The entrance is to find allList { ForEach(...) }andTable { ForEach(...) }, confirm that only one view is generated for each element.

4. Put.taskAs the default way to load data

if you areonAppearCall the synchronization method to obtain data, or ininit()When making network requests, change it to.task { await model.load() }asynchronous mode. This prevents the interface from freezing and allows SwiftUI to automatically cancel tasks when the view disappears. The entrance is to change the synchronous loading method toasync, then add.taskmodifier.

5. UseinspectorColumnWidthCheck performance while debugging layout

Custom presentation of the Inspector and Sheet also involves view reconstruction. If you’re displaying a lot of data in the Inspector, make sure the Inspector’s content view follows the same dependency minimization principles.
