Bring your game to Mac, Part 3: Render with Metal

Highlight

This is the final chapter in the trilogy of porting games to Mac. It explains how to port the renderer to Metal, covering four core topics: resource binding and persistence, command submission optimization, indirect rendering, and MetalFX super-resolution.

Core Content

From Root Signature to Argument Buffer

Direct3D uses Root Signature to describe resource bindings. A typical Root Signature has four entries: texture descriptor table, buffer parameters, 32-bit constants, and sampler descriptor table.

Metal’s Argument Buffer is more flexible and supports mixed type elements. But it’s also easy to code if the engine expects a homogeneous array.

Encoded texture descriptor table:

// Create the texture table outside the render loop
id<MTLBuffer> textureTable = [device newBufferWithLength:sizeof(MTLResourceID) * texturesCount
                                                 options:MTLResourceStorageModeShared];

MTLResourceID* textureTableCPUPtr = (MTLResourceID*)textureTable.contents;
for (uint32_t i = 0; i < texturesCount; ++i) {
    // Create the texture
    id<MTLTexture> texture = [device newTextureWithDescriptor:textureDesc[i]];
    // Store the texture GPU resource ID in the table
    textureTableCPUPtr[i] = texture.gpuResourceID;
}

Key Points:

• MTLResourceID is a resource identifier introduced in Metal 3
• The texture table is created during the initialization phase, not in the rendering loop
• gpuResourceID directly obtains the GPU side identifier of the texture

(03:55)

Encoding sampler descriptor table:

id<MTLBuffer> samplerTable = [device newBufferWithLength:sizeof(MTLResourceID) * samplersCount
                                                 options:MTLResourceStorageModeShared];

MTLResourceID* samplerTableCPUPtr = (MTLResourceID*)samplerTable.contents;
for (uint32_t i = 0; i < samplersCount; ++i) {
    MTLSamplerDescriptor* desc = [MTLSamplerDescriptor new];
    desc.supportArgumentBuffers = YES;  // Required
    // ... Configure other sampler properties

    id<MTLSamplerState> sampler = [device newSamplerStateWithDescriptor:desc];
    samplerTableCPUPtr[i] = sampler.gpuResourceID;
}

Key Points:

• supportArgumentBuffers = YES is the prerequisite for the sampler to be put into the Argument Buffer
• Like the texture table, the sampler table is also created during the initialization phase

(04:33)

Encoding the top-level Argument Buffer:

struct TopLevelAB {
    MTLResourceID* textureTable;
    float*         myBuffer;
    uint32_t       myConstant;
    MTLResourceID* samplerTable;
};

id<MTLBuffer> topAB = [device newBufferWithLength:sizeof(TopLevelAB)
                                          options:MTLResourceStorageModeShared];

TopLevelAB* topABCPUPtr = (TopLevelAB*)topAB.contents;
topABCPUPtr->textureTable = (MTLResourceID*)textureTable.gpuAddress;
topABCPUPtr->myBuffer     = (float*)myBuffer.gpuAddress;
topABCPUPtr->myConstant   = 128;
topABCPUPtr->samplerTable = (MTLResourceID*)samplerTable.gpuAddress;

Key Points:

• The top-level structure corresponds to the four entries of Root Signature
• gpuAddress Get the GPU address of the subtable
• Only need to bind this top-level buffer in the rendering loop: [encoder setVertexBuffer:topAB offset:0 atIndex:0]

(05:05)

Resource residency management

Bindless resources require explicit management of residency. Core recommendations:

Read-only resource: Grouped into a large Heap, called once per encoder useHeap.

// Create the heap
MTLHeapDescriptor* heapDesc = [MTLHeapDescriptor new];
heapDesc.size = requiredSize;
heapDesc.type = MTLHeapTypeAutomatic;
id<MTLHeap> heap = [device newHeapWithDescriptor:heapDesc];

// Allocate textures and buffers from the heap
id<MTLTexture> texture = [heap newTextureWithDescriptor:desc];
id<MTLBuffer> buffer = [heap newBufferWithLength:length options:options];

// Mark the entire heap resident at once during rendering
[encoder useHeap:heap];

Key Points:

• Heap’s hazard tracking mode is set to Untracked
• All read-only resources are allocated from one Heap
• Only one useHeap call per encoder

(06:49)

Writable resources: Allocate separately, specify the usage flag with useResource, and let Metal handle the synchronization.

// Allocate writable resources separately
id<MTLTexture> textureRW = [device newTextureWithDescriptor:desc];
id<MTLBuffer> bufferRW = [device newBufferWithLength:length options:options];

// Mark resources resident and specify read/write flags
[encoder useResource:textureRW usage:MTLResourceUsageWrite stages:stage];
[encoder useResource:bufferRW usage:MTLResourceUsageRead stages:stage];

Key Points:

• Do not put writable resources into Heap
• Explicitly specify read and write intentions with useResource
• Metal automatically handles hazard tracking and synchronization across encoders

(07:34)

Command submission optimization

Apple GPU is a TBDR (Tile-Based Deferred Renderer) architecture with unified memory and on-chip Tile Memory. Metal uses the Pass concept, which requires commands to be grouped by type.

Problem sequence before optimization: Clear → Draw → Copy → Calculate → Draw. This sequence has 5 round trips between Tile Memory and system memory.

Optimization steps:

1. Move the copy operation before rendering starts
2. Group commands by type: Put drawing commands together and calculation commands together
3. Merge Passes that share the same render target
4. Use LoadActionClear instead of empty encoder clear
5. Optimize Store Action: Store render target content only when needed

After optimization, there is only one final flush left, and the memory bandwidth is greatly reduced.

(10:53)

Metal Debugger automatically discovers optimization opportunities

Xcode’s Metal Debugger lists optimization suggestions in the Insights section of the Summary viewer, divided into four categories: Memory, Bandwidth, Performance, and API Usage.

Example: GBuffer Pass stores more attachments than needed. The Albedo texture is not used in subsequent frames and the Store operation is redundant. The fix is ​​to set the store action to DontCare.

Another example: the two Passes GBuffer and Forward can be merged because they read and write the same attachment. Save bandwidth after merging.

Dependencies viewer can view the data flow between Passes, confirm load/store actions and merge opportunities.

(15:06)

Detailed Content

Indirect rendering

ExecuteIndirect stores the parameters of multiple drawing commands into a buffer, and the GPU reads the parameters from the buffer to execute drawing. This allows the GPU to decide what to render and is key to implementing a GPU-driven rendering loop.

Metal has two translation methods:

Method 1: Draw Indirect

// Translate ExecuteIndirect into a series of drawIndexedPrimitives calls
uint32_t drawArgumentsBufferOffset = 0;
for (uint32_t i = 0; i < maxDrawCount; ++i) {
    [renderEncoder drawIndexedPrimitives:MTLPrimitiveTypeTriangle
                              indexType:MTLIndexTypeUInt16
                            indexBuffer:indexBuffer
                      indexBufferOffset:indexBufferOffset
                         indirectBuffer:drawArgumentsBuffer
                   indirectBufferOffset:drawArgumentsBufferOffset];

    drawArgumentsBufferOffset += sizeof(MTLDrawIndexedPrimitivesIndirectArguments);
}

Key Points: -Each draw command is coded individually

• Read different indirect parameters by offset
• Simple to implement and suitable for most scenarios

(19:31)

Method 2: Indirect Command Buffer (ICB)

Use ICB when the scene has thousands of draw commands and CPU encoding time is the bottleneck. ICB encodes commands on the GPU, including setting pipeline state and buffer binding.

// Compute kernel: translate indirect draw arguments into ICB commands
kernel void translateToICB(device const Command* indirectCommands [[buffer(0)]],
                           device const ICBContainerAB* icb [[buffer(1)]],
                           ...)
{
    device const Command* indirectCommand = &indirectCommands[commandIndex];
    device const MTLDrawIndexedPrimitivesIndirectArguments* args =
        &command->mdiBuffer[mdiIndex];

    render_command drawCall(icb->buffer, indirectCommand->mdiCmdStart + mdiIndex);

    if (args->indexCount > 0 && args->instanceCount > 0) {
        encodeCommand(indirectCommand, args, drawCall);
    } else {
        cmd.reset();
    }
}

void encodeCommand(device const Command* indirectCommand,
                   device const MTLDrawIndexedPrimitivesIndirectArguments* args,
                   thread render_command& drawCall)
{
    drawCall.set_render_pipeline_state(indirectCommand->pso);

    for (ushort i = 0; i < indirectCommand->vertexBuffersCount; ++i) {
        drawCall.set_vertex_buffer(indirectCommand->vertexBuffer[i].buffer,
                                   indirectCommand->vertexBuffer[i].slot);
    }

    drawCall.draw_indexed_primitives(primitive_type::triangle,
                                     args->indexCount,
                                     indirectCommand->indexBuffer + args->indexStart,
                                     args->instanceCount,
                                     args->baseVertex,
                                     args->baseInstance);
}

Key Points:

• ICB commands are encoded on the GPU, reducing CPU overhead
• No need to split indirect execution commands for each state change
• Can reuse existing indirect parameter generation shaders

(21:48)

MetalFX Super Resolution

MetalFX lets games render at a lower resolution and then oversample to the target resolution, saving GPU time per frame.

MetalFX supports two algorithms:

• Spatial: Best performance
• Temporal: Quality close to native resolution rendering

New this year: iOS support, up to 3x supersampling, Metal-cpp support.

Integrating MetalFX requires:

1. The engine supports super-resolution
2. The renderer manually controls the level of detail of texture sampling.
3. Temporal supersampling requires dither sequences and motion vectors (already available if TAA already exists)

(22:54)

Core Takeaways

• What to build: Port existing Root Signature binding model with Argument Buffer

  • Why it’s worth doing: Metal 3’s Argument Buffer has higher performance and can fully map Direct3D’s descriptor table concept
  • How to start: Encode the texture table and sampler table during the initialization phase, and the rendering loop only binds the top-level Argument Buffer

• What to build: Automatically discover bandwidth optimization opportunities with Metal Debugger’s Insights feature

  • Why it’s worth doing: You can intuitively see which Passes can be merged and which Store operations are redundant
  • How to start: To capture a Metal workload in Xcode, view the Insights section of the Summary viewer

• What to build: Use Indirect Command Buffer in CPU encoding bottleneck scenarios

  • Why it’s worth doing: Move command encoding from CPU to GPU, significantly reducing CPU overhead
  • How to start: Add a calculation kernel to translate indirect drawing parameters into ICB commands, and then execute them with executeCommandsInBuffer

• What to build: Integrated MetalFX Upscaling to improve frame rate

  • Why it’s worth doing: Render at a lower resolution and then oversample to get significant performance improvements on Apple Silicon
  • How to start: Confirm that the engine supports super-resolution and manual LOD control, select Spatial or Temporal algorithm
